New Question 1:
Refer to the exhibit. Which type of route does R1 use to reach host 10.10.13.10/32?
A. default route
B. network route
C. host route
D. floating static route
Correct Answer: B
New Question 2:
Refer to the exhibit. Which prefix does CertBus-R use to Host A?
A. 10.10.10.0/28
B. 10.10.13.0/25
C. 10.10.13.144/28
D. 10.10.13.208/29
Correct Answer: D
Host A address fall within the address range. However, if more than one route to the same subnet exists (the router will use the longest stick match, which matches the more specific route to the subnet). If there are routes 10.10.13.192/26 and 10.10.13.208/29, the router will forward the packet to /29 rather than /28.
New Question 3:
A frame that enters a switch fails the Frame Check Sequence. Which two interface counters are incremented? (Choose two.)
A. input errors
B. frame
C. giants
D. CRC
E. runts
Correct Answer: AD
Whenever the physical transmission has problems, the receiving device might receive a frame whose bits have changed values. These frames do not pass the error detection logic as implemented in the FCS field in the Ethernet trailer. The
receiving device discards the frame and counts it as some kind of input error. Cisco switches list this error as a CRC error. Cyclic redundancy check (CRC) is a term related to how the FCS math detects an error.
The “input errors” includes runts, giants, no buffer, CRC, frame, overrun, and ignored counts.
The output below shows the interface counters with the “show interface s0/0/0” command:
New Question 4:
How do TCP and UDP differ in the way that they establish a connection between two endpoints?
A. TCP uses the three-way handshake, and UDP does not guarantee message delivery.
B. TCP uses synchronization packets, and UDP uses acknowledgment packets.
C. UDP provides reliable message transfer, and TCP is a connectionless protocol.
D. UDP uses SYN, SYN-ACK, and FIN bits in the frame header while TCP uses SYN, SYN-ACK, and ACK bits.
Correct Answer: A
New Question 5:
Which 802.11 frame type is an association response?
A. management
B. protected frame
C. action
D. control
Correct Answer: A
Reference: https://en.wikipedia.org/wiki/802.11_Frame_Types
New Question 6:
In which way does a spine-and-leaf architecture allow for scalability in a network when additional access ports are required?
A. A spine switch and a leaf switch can be added with redundant connections between them.
B. A spine switch can be added with at least 40 GB uplinks.
C. A leaf switch can be added with connections to every spine switch.
D. A leaf switch can be added with a single connection to a core spine switch.
Correct Answer: C
Spine-leaf architecture is typically deployed as two layers: spines (such as an aggregation layer), and leaves (such as an access layer). Spine-leaf topologies provide high-bandwidth, low-latency, nonblocking server-to-server connectivity.
Leaf (aggregation) switches are what provide devices access to the fabric (the network of spine and leaf switches) and are typically deployed at the top of the rack. Generally, devices connect to the leaf switches.
Devices can include servers, Layer 4-7 services (firewalls and load balancers), and WAN or Internet routers. Leaf switches do not connect to other leaf switches. In spine-and-leaf architecture, every leaf should connect to every spine in a full
mesh.
Spine (aggregation) switches are used to connect to all leaf switches and are typically deployed at the end or middle of the row. Spine switches do not connect to other spine switches.
New Question 7:
Which statement identifies the functionality of virtual machines?
A. The hypervisor communicates on Layer 3 without the need for additional resources.
B. Each hypervisor can support a single virtual machine and a single software switch.
C. The hypervisor can virtual physical components including CPU, memory, and storage.
D. Virtualized servers run most efficiently when they are physically connected to a switch that is separate from the hypervisor.
Correct Answer: C
New Question 8:
Which command automatically generates an IPv6 address from a specified IPv6 prefix and MAC address of an interface?
A. ipv6 address DHCP
B. ipv6 address 2001:DB8:5:112::/64 eui-64
C. ipv6 address autoconfig
D. ipv6 address 2001:DB8:5:112::2/64 link-local
Correct Answer: C
The “ipv6 address autoconfig” command causes the device to perform IPv6 stateless address auto-configuration to discover prefixes on the link and then add the EUI-64-based addresses to the interface. Addresses are configured depending on the prefixes received in Router Advertisement (RA) messages. The device will listen for RA messages which are transmitted periodically from the router (DHCP Server). This RA message allows a host to create a global IPv6 address from:
1.
Its interface identifier (EUI-64 address)
2.
Link Prefix (obtained via RA)
Note: Global address is the combination of Link Prefix and EUI-64 address
New Question 9:
When configuring IPv6 on an interface, which two IPv6 multicast groups are joined? (Choose two.)
A. 2000::/3
B. 2002::5
C. FC00::/7
D. FF02::1
E. FF02::2
Correct Answer: DE
When an interface is configured with an IPv6 address, it automatically joins all nodes (FF02::1) and solicited-node (FF02::1:FFxx: XXXX) multicast groups. The all-node group is used to communicate with all interfaces on the local link, and the solicited-nodes multicast group is required for link-layer address resolution. Routers also join a third multicast group, the all-routers group (FF02::2).
New Question 10:
What is the default behavior of a Layer 2 switch when a frame with an unknown destination MAC address is received?
A. The Layer 2 switch forwards the packet and adds the destination MAC address to its MAC address table.
B. The Layer 2 switch sends a copy of a packet to the CPU for destination MAC address learning.
C. The Layer 2 switch floods packets to all ports except the receiving port in the given VLAN.
D. The Layer 2 switch drops the received frame.
Correct Answer: C
If the destination MAC address is not in the CAM table (unknown destination MAC address), the switch sends the frame out to all other ports that are in the same VLAN as the received frame. This is called flooding. It does not flood the frame out of the same port on which the frame was received.
New Question 11:
An engineer must configure a /30 subnet between two routes. Which usable IP address and subnet mask combination meets this criteria?
A. interface e0/0 description to HQ-A370:98968 IP address 10.2.1.3 255.255.255.252
B. interface e0/0 description to HQ-A370:98968 IP address 192.168.1.1 255.255.255.248
C. interface e0/0 description to HQ-A370:98968 IP address 172.16.1.4 255.255.255.248
D. interface e0/0 description to HQ-A370:98968 IP address 209.165.201.2 225.255.255.252
Correct Answer: D
New Question 12:
Which network allows devices to communicate without the need to access the Internet?
A. 172.9.0.0/16
B. 172.28.0.0/16
C. 192.0.0.0/8
D. 209.165.201.0/24
Correct Answer: B
This question asks about the private ranges of IPv4 addresses. The private ranges of each class of IPv4 are listed below:
1.
Class A private IP address ranges from 10.0.0.0 to 10.255.255.255
2.
Class B private IP address ranges from 172.16.0.0 to 172.31.255.255
3.
Class C private IP address ranges from 192.168.0.0 to 192.168.255.255
Only network 172.28.0.0/16 belongs to the private IP address (of class B).
New Question 13:
Refer to exhibit.
Which statement explains the configuration error message that is received?
A. It belongs to a private IP address range.
B. The router does not support the/28 mask.
C. It is a network IP address.
D. It is a broadcast IP address.
Correct Answer: D
New Question 14:
Which IPv6 address type communication between subnets cannot route on the Internet?
A. link-local
B. unique local
C. multicast
D. global unicast
Correct Answer: B
An IPv6 Unique Local Address is an IPv6 address in the block FC00::/7. It is the approximate IPv6 counterpart of the IPv4 private address. It is not routable on the global Internet.
Note: In the past, Site-local addresses (FEC0::/10) are equivalent to private IP addresses in IPv4 but now they are deprecated.
Link-local addresses are only used for communications within the local subnet. It is usually created dynamically using a link-local prefix of FE80::/10 and a 64-bit interface identifier (based on a 48-bit MAC address).
New Question 15:
Which IPv6 address block sends packets to a group address rather than a single address?
A. 2000::/3
B. FC00::/7
C. FE80::/10
D. FF00::/8
Correct Answer: D
